WIPER ARM TR4/5 LH, RHD cranked HEAVY DUTY wedge lock

Part No:

131106X

Price

£55.30

Price Ex VAT @ 20%

£46.08

IN STOCK This part is immediately available

2 images

About This Part

TR4, 4A, 250, 5 Left Hand Wiper Arm for Right Hand Drive cars uprated. Heavy-duty design incorporating a Wedge Lock type drive head incorperating a screwed clamp to the serrated spindle.

The wedge Lock feature provides a serrated wedge acting on the drive boss, tightened by an external screw. When the screw is tightened the wedge is forced against the boss for a firm fit however worn the boss is, ideal when the aluminium serrated spindle head is worn and will not hold a standard arm. All Rally cars should use this arm.

This arm has a 38° cranked bend to avoid the vent flap when open.

Technical Description

Drive Head: Wedge Lock
Length: 305mm
Blade Fitting: Bayonet
Arm Width: 5.2mm
Degrees of Crank: 38 in the middle of the arm, none at the bayonet end
Direction of crank: Left
How To Measure The Length: Centre of drive to the end of the arm

For a complete solution, use these arms in conjunction with blades GWB219 with insert RTR8521-40 and our improved wiper motor kit RTR8395-BK for TR4-4A and RTR8395-CK for TR250 and TR5.

No catalogue plates are available

Part No.	Description and Comments	Price	Add to Cart
GWB219 CLICK FOR MORE INFO	WIPER BLADE TR4, 4A, 250 and 5 STAINLESS steel 10" Revington TR information: Windscreen Wiper Blade to suit narrow wiper arm fitted to TR4, 4A ,250 and 5 (as opposed to the slightly thicker arm used on TR6), Bright finish. Consider also modern silicone rubber insert RTR8521-40. This inset... READ MORE	£20.70 Ex VAT @ 20% £17.25	Available to order
RTR8521-40 CLICK FOR MORE INFO	WIPER REFILL SILICONE 16"	£15.00 Ex VAT @ 20% £12.50
131105X CLICK FOR MORE INFO	WIPER ARM TR4/5 RH, RHD straight HEAVY DUTY Wedge lock Revington TR information: TR4, 4A, 250 and 5 Right Hand Wiper Arm for Right Hand Drive cars. Heavy-duty design incorporating a Wedge Lock type drive head incorperating a screwed clamp to the serrated spindle. The wedge Lock feature provides... READ MORE	£55.30 Ex VAT @ 20% £46.08	Available to order
RTR8395-BK CLICK FOR MORE INFO	WIPER UPGRADE KIT TR4-4A Revington TR information: Conversion Kit to upgrade the wiper system to replace the notoriously poor standard Motor and Wheelbox with a Heavy Duty Motor and Wheelboxes. The kit Includes all fittings and Instructions. TR4 and TR4A Wiper Systems are... READ MORE	£1068.72 Ex VAT @ 20% £890.60	Available to order
RTR8395-CK CLICK FOR MORE INFO	WIPER UPGRADE KIT TR250,5 Revington TR information: Conversion Kit to upgrade the wiper system to replace the notoriously poor standard Motor and Wheelboxes with a Heavy Duty Motor and Wheelboxes. The kit includes all fittings and Instructions. TR5 and TR250 Wiper Systems are... READ MORE	£994.80 Ex VAT @ 20% £829.00	Available to order
131106 CLICK FOR MORE INFO	WIPER ARM LH TR4/5 RHD cranked Revington TR information: TR4, 4A, 250 and 5 Left Hand Wiper Arm for Right Hand Drive cars, standard type. This arm has a 38° cranked bend to avoid the vent flap when open. Consider using heavy-duty part 131106X... READ MORE	£39.80 Ex VAT @ 20% £33.17
131105 CLICK FOR MORE INFO	WIPER ARM RH TR4-5 RHD straight Revington TR information: TR4, 4A, 250 and 5 Right Hand Wiper Arm for Right Hand Drive cars, standard type. This arm is straight with a slight crank at the end of the arm. It is 11" long from... READ MORE	£39.80 Ex VAT @ 20% £33.17
