TR6 CC Plate L - ENGINE (Carburettor Model): Air Cleaner and Silencer
<< Return to Triumph Catalogue Plate ListAlso in this listing
Air Cleaner and Silencer Assembly, Ignition leadsPlate No. | Part No. | Description and Comments | No Per Unit | Price | Add to Cart | |
---|---|---|---|---|---|---|
L1AA | 148636 |
AIR CLEANER AND SILENCER ASSEMBLYTriumph Catalogue Remarks: Fitted up to Engine No. CC50,000 |
1 | |||
L1AB | 154223 |
AIR CLEANER AND SILENCER ASSEMBLYTriumph Catalogue Remarks: Fitted from Engine No. CC50,001 up to CC67,483 |
1 | |||
L1AC | 156268 |
AIR CLEANER AND SILENCER ASSEMBLYTriumph Catalogue Remarks: Fitted from Engine No. CCCC67,484 up to 75,000 |
1 | |||
L1AD | 157736 |
AIR CLEANER AND SILENCER ASSEMBLYTriumph Catalogue Remarks: Fitted from Engine No. CC75,001 |
1 | |||
L1 | 214468 |
COVER, top, and silencer tube assemblyRevington TR information: no longer available use 214468SH |
1 | |||
L1A | 218044 |
COVER, top assemblyTriumph Catalogue Remarks: Fitted up to Engine No. CC75,000 |
1 | |||
L1B | 157735 |
COVER, top assemblyTriumph Catalogue Remarks: Fitted from Engine No. CC75,001 |
1 | |||
L2 | 214466 |
PLATE, back, assemblyTriumph Catalogue Remarks: Fitted up to Engine No. CC50,000 |
1 | |||
L2A | 216489 |
PLATE, back, assemblyTriumph Catalogue Remarks: Fitted from Engine No. CC50,001 up to CC67,483 |
1 | |||
L2B | 217499 |
PLATE, back, assemblyTriumph Catalogue Remarks: Fitted from Engine No. CC67,484 up to CC75,000 |
1 | |||
L3 | 148600 |
ELEMENT, filterThis item has been superceded by GFE1020 - see below |
2 | |||
GFE1020 |
FILTER ELEMENT TR250 |
2 |
£7.90 Ex VAT @ 20% |
|||
L4 | 148599 |
GASKET, between element, back plate and cover |
4 |
£3.77 Ex VAT @ 20% |
||
L5 | HB0868 |
BOLT Air cleaner to carburettors |
6 | |||
L6 | WL0208 |
WASHER, lock - Air cleaner to carburettorsThis item has been superceded by WS105090853 - see below |
6 | |||
WS105090853 |
WASHER SPRING 5/16" ID RECT SECTION |
6 |
£0.25 Ex VAT @ 20% |
|||
IGNITION |
||||||
L6A | 148957 |
PLUG, sparkingThis item has been superceded by BP6ES - see below |
6 | |||
BP6ES |
SPARK PLUG TR5,TR6 & TR7Revington TR information: This is the standard spark plug we use for TR5, TR6, TR7. Consider cutting edge technology plugs BPR6EIX and IW20. |
6 |
£5.50 Ex VAT @ 20% |
|||
H.T. LEADS |
||||||
L6B | 150550 |
ENGINE LEAD ASSEMBLY, No. 1 |
1 |
£13.64 Ex VAT @ 20% |
||
L6C | 150551 |
ENGINE LEAD ASSEMBLY, No. 2Revington TR information: Ripaults supressed 25Kohm/M 340mm long straight rubber boots both ends |
1 |
£13.64 Ex VAT @ 20% |
||
L6D | 150552 |
ENGINE LEAD ASSEMBLY, No. 3 |
1 |
£13.64 Ex VAT @ 20% |
||
L6E | 150553 |
ENGINE LEAD ASSEMBLY, No. 4Triumph Catalogue Remarks: Fitted up to Engine No. ....... |
1 |
£13.64 Ex VAT @ 20% |
||
L6F | 150548 |
ENGINE LEAD ASSEMBLY, No. 4Triumph Catalogue Remarks: Fitted from Engine No. ....... |
1 |
£13.64 Ex VAT @ 20% |
||
L6G | 150554 |
ENGINE LEAD ASSEMBLY, No. 5Triumph Catalogue Remarks: Fitted up to Engine No. ....... |
1 |
£13.64 Ex VAT @ 20% |
||
L6H | 150548 |
ENGINE LEAD ASSEMBLY, No. 5Triumph Catalogue Remarks: Fitted from Engine No. ....... |
1 |
£13.64 Ex VAT @ 20% |
||
L6I | 150555 |
ENGINE LEAD ASSEMBLY, No. 6Revington TR information: Ripaults supressed 25Kohm/M 280mm long straight rubber boots both ends |
1 |
£13.64 Ex VAT @ 20% |
||
L6J | 146113 |
ENGINE LEAD, coil to distributorThis item has been superceded by GHT144 - see below |
1 | |||
GHT144 |
PLUG LEAD SET TR5-6Revington TR information: TR5 6 carbon leads. Straight connectors into distributor cap. |
1 |
£34.81 Ex VAT @ 20% |
